Overview

The cross-cutting concerns every addon author hits regardless of which kind they're building. If something in a kind-specific page assumes a piece of background, it's described here.

Note that the catalog → invoke arrow is dashed: addon implementation modules are not loaded at startup. The .gpr.py is what runs during discovery; the fname module only loads on first use. This is why a registration-time error blocks the whole addon from appearing, but a runtime error in the implementation only surfaces when the user triggers it.

The `.gpr.py` registration file

Every addon ships exactly one .gpr.py per folder, executed at startup by Gramps' plugin scanner. Its single job is to call register(...) one or more times, declaring the addon's metadata — what kind it is, what version of Gramps it targets, which implementation module to load on demand.

The general shape:

register(
    GRAMPLET,                          # kind (see 04-addon-kinds)
    id="HelloGramplet",                # stable identifier — folder name
    name=_("Hello Gramplet"),          # user-visible label
    description=_("A minimal example"),
    version="1.0.0",                   # addon version, X.Y.Z
    gramps_target_version="6.0",       # which Gramps minor this targets
    status=STABLE,                     # STABLE / BETA / EXPERIMENTAL / UNSTABLE
    fname="hellogramplet.py",          # implementation module
    # kind-specific fields go here
    gramplet="HelloGramplet",
    gramplet_title=_("Hello"),
)

Fields every kind needs

Field	Meaning
`id`	Stable identifier; MUST match the folder name
`name`	User-visible label, translatable
`version`	Addon version, dotted `X.Y.Z`
`gramps_target_version`	The Gramps minor this targets, e.g. `"6.0"`
`status`	`STABLE`, `BETA`, `EXPERIMENTAL`, or `UNSTABLE`
`fname`	The implementation module Gramps loads on first use

Fields most kinds want

description — shown in the Plugin Manager tooltip.
authors, authors_email — credit and contact, both lists.
maintainers, maintainers_email — only set if different from authors.
help_url — wiki page name; Gramps prepends the base URL and may add a language extension. Don't wrap in _() unless you actually want per-language wiki pages.
audience — EVERYONE (default), EXPERT, or DEVELOPER; filters visibility in the Plugin Manager. The constants live at _pluginreg.py:75-77 — note EVERYONE, not ALL (an outdated wiki page documents ALL; the code has only ever used EVERYONE).

Kind-specific fields

Every kind adds its own. A few examples:

GRAMPLET adds gramplet (class or function name), gramplet_title, height, expand, navtypes, force_update.
REPORT adds reportclass, optionclass, category, report_modes, require_active.
TOOL adds toolclass, optionclass, category, tool_modes.
QUICKVIEW adds runfunc, category.

04-addon-kinds lists the kind-specific fields per kind. The authoritative reference is the expand_* helpers in _pluginreg.py.

Multiple registrations per file

A single .gpr.py may call register(...) more than once — for example a report that also exposes a quick view, or two related gramplets sharing one implementation module. Each call is independent metadata.

Plugin discovery

Gramps walks the plugin path at startup, executes every .gpr.py it finds, and builds an in-memory catalog from each register() call. The implementation modules pointed to by fname are not loaded at this point — they're imported lazily on first invocation. This split matters for diagnostics:

A SyntaxError or import failure in .gpr.py makes the addon disappear entirely from menus — the catalog never got an entry for it.
A failure inside the implementation module surfaces only when the user triggers the addon, with a traceback in the Plugin Manager and the log window.

The plugin path

Plugin folders are searched under each path Gramps was configured to scan — typically the system-wide plugin dir plus the per-user plugin dir. The per-user dir is the safe one to develop in; system locations generally need elevated permissions and shouldn't be edited directly. The exact paths are platform-specific; the Addons page lists them.

Symlinks

Plugin discovery's symlink handling changed between 6.0 and 6.1:

Gramps 6.0 — symlinks are not followed. An addon symlinked in is invisible. Development loop: copy/rsync from working tree on save.
Gramps 6.1+ — symlinks are followed, with realpath-based dedup so cycles terminate. Symlinking the working tree into the user plugin dir works in place. (Gramps commit 9443dcbb30 on maintenance/gramps61.) The symlink test is skipped on Windows because the platform's symlink behaviour is inconsistent without elevated privileges; on Windows, a physical copy remains the safe approach even on 6.1+.

Concrete sync recipes live in 02-get-started.

Names Gramps injects into `.gpr.py`

The .gpr.py runs in a scope where several names are pre-populated by the plugin loader. You must not import them; Gramps puts them there and an import masks them with stale bindings.

Injected name	Source
`register`	the loader itself
`_` (and `ngettext`)	the addon's local translation
Kind constants — `GRAMPLET`, `REPORT`, `TOOL`, …	`gramps.gen.plug._pluginreg`
Status constants — `STABLE`, `BETA`, `EXPERIMENTAL`, `UNSTABLE`	`_pluginreg.py:62-65`
Audience constants — `EVERYONE`, `EXPERT`, `DEVELOPER`	`_pluginreg.py:75-77`
Report category constants — `CATEGORY_TEXT`, `CATEGORY_DRAW`, …	`_pluginreg.py:141-149`
Tool category constants — `TOOL_DBPROC`, `TOOL_DBFIX`, …	`_pluginreg.py:154-159`
Quick View category constants — `CATEGORY_QR_PERSON`, …	`_pluginreg.py:163-174`
Report mode constants — `REPORT_MODE_GUI`, `REPORT_MODE_BKI`, …	`_pluginreg.py`

In the implementation module, none of these are injected — the rules are normal Python. Import what you need from gramps.gen.* there.

Translation

Every user-visible string in the .gpr.py and in the implementation goes through _(). The function is set up differently in the two files because the .gpr.py runs in the injected-name scope.

In .gpr.py: just use _(). The loader has already wired it.

register(
    GRAMPLET,
    id="HelloGramplet",
    name=_("Hello"),
    description=_("A minimal example"),
    ...
)

In the implementation module: opt into the addon's own translation catalog at the top of the file, then use _() normally.

from gramps.gen.const import GRAMPS_LOCALE as glocale

_ = glocale.get_addon_translator(__file__).gettext

This binds _ to translations stored in the addon's own po/ folder rather than Gramps' core catalog. Without this line, _() falls back to the core catalog and your addon-specific strings stay in English regardless of UI language.

Plurals

Use ngettext(singular, plural, n) whenever a number is being formatted into a string. Languages with non-trivial plural rules (Russian, Polish, …) need both forms to render correctly.

msg = ngettext("{n} match", "{n} matches", n).format(n=n)

Disambiguating contexts

When the same English word translates differently in different contexts, add a context hint. Gramps' _() accepts _(msg, context); the older pgettext(context, msg) form also works but the comma form is preferred because the source remains readable as plain English.

_("Source", "citation")   # vs. _("Source", "person attribute")

Logging

Use a module-level logger; never use print() for diagnostics.

import logging

LOG = logging.getLogger(".".join(__name__.split(".")[-2:]))
# or simply:
LOG = logging.getLogger(__name__)

LOG.debug("Reached the interesting branch with n=%d", n)
LOG.warning("Skipping malformed event %s", event.gramps_id)

Log output flows into:

The Gramps log window (Help → Log) — visible to the user.
stderr when Gramps is launched with --debug or with GRAMPS_DEBUG=1 set.

See 09-debug for how to enable debug levels per logger.

Lifecycle hooks

Every kind has its own entry points; the shape varies, but the pattern is consistent: a small number of named methods that Gramps calls at specific moments, and you override the ones you need.

Gramplets

Subclass gramps.gen.plug.Gramplet. The hooks Gramps calls:

Method	When
`init(self)`	Once, on first show. Build the UI here. Don't read the DB yet — it may not be open.
`db_changed(self)`	When the active database changes. Reconnect any signals you wired on the old DB.
`active_changed(self, handle)`	When the active person / family / etc. changes. Default is to call `update()`.
`main(self)`	The work itself. May be a generator — `yield True` to keep going, `yield False` to stop.
`update(self)`	Don't override. Calls `main()` for you; you call `update()` to schedule a redraw.
`on_load(self)` / `on_save(self)`	When the gramplet's persistent data is loaded / saved.

Inside the class, self.dbstate.db is your live database, self.uistate is the GUI state. See 06-data-access for what you can do with self.dbstate.db.

Reports

Subclass gramps.gen.plug.report.Report. The constructor receives (database, options_class, user). Override write_report() — that's the single hook Gramps calls. Everything else is plumbing you initialise in __init__.

Tools

Subclass from gramps.gui.plug.tool. The constructor receives (dbstate, user, options_class, name, callback=None) and does the work inline (there's no separate run() for non-CLI tools). For CLI mode, tool_modes=[TOOL_MODE_CLI] triggers a different entry path.

Quick Views

Plain function: run(database, document, person_or_family_or_…). No class to subclass. Point runfunc at it in the registration.

Importers / Exporters

Plain function pointed to by fname + the kind's entry-point field. Signature varies by kind and minor; reading a live importer/exporter is the most reliable way to lock down the exact shape on your target branch.

Signals: addons reacting to changes

Gramps' database and UI emit signals when state changes. Addons that need to stay in sync — gramplets that refresh on data changes, views that follow the selection — connect() to those signals.

The minimal pattern

key = self.dbstate.db.connect("person-update", self.cb_person_changed)
# … later, in teardown …
self.dbstate.db.disconnect(key)

connect() returns an opaque key; pass it to disconnect() when the addon shuts down or the database changes. Forgetting to disconnect leaves stale callbacks pointing into freed objects and crashes Gramps sooner or later.

The signals that matter most

Source	Signal	When
`dbstate.db`	`person-add`, `family-add`, `event-add`, …	One object added. Arg: list of handles.
`dbstate.db`	`person-update`, `family-update`, …	One object updated. Arg: list of handles.
`dbstate.db`	`person-delete`, `family-delete`, …	One object deleted. Arg: list of handles.
`dbstate.db`	`person-rebuild`, `family-rebuild`, …	Mass change (import, db repair). No args.
`dbstate.db`	`home-person-changed`	Home person changed. No args.
`dbstate`	`database-changed`	Active database swapped. Arg: the new db.
`dbstate`	`no-database`	No db is open.
`uistate`	`nameformat-changed`, `filter-name-changed`, …	Various UI preferences.
view's history	`active-changed`	Selected object changed. Arg: the new handle.

Pattern: person-update / family-update / etc. fire one after a transaction commits, with a list of affected handles. They never fire mid-transaction, so callbacks can safely re-read the DB.

Subscribing to "anything changed"

A common gramplet pattern is "redraw on any structural change to the tree", typically done by wiring db_changed:

def db_changed(self):
    self.dbstate.db.connect("person-add",    self.update)
    self.dbstate.db.connect("person-delete", self.update)
    self.dbstate.db.connect("person-update", self.update)
    self.dbstate.db.connect("family-add",    self.update)
    self.dbstate.db.connect("family-delete", self.update)
    self.dbstate.db.connect("family-update", self.update)

For complex subscriptions across many object types, the CallbackManager in gramps.gen.utils.callman is a higher-level filter that lets you register dictionaries of {signal: handler} and tracks keys for disconnect_all() on teardown. See Signals and callbacks for the full inventory.

Signal ordering

Signals are deferred until a transaction commits and are emitted in a specific order: deletes first, then adds, then updates; within each phase, by object type in the order persons → families → sources → events → media → places → repositories → notes → tags → citations. This deterministic order matters when a single transaction touches related objects (a family merge deletes one family and updates another plus its members); a handler that re-reads the DB on person-delete will see a consistent state.

Reading and writing the database

The DB API is covered in depth in 06-data-access. The rule worth stating here, where every addon meets it:

Reading is unrestricted. Any addon may read freely from self.dbstate.db.

Writing goes through a transaction. Always:

with DbTxn(_("Description for Undo history"), db) as trans:
    person = db.get_person_from_handle(handle)
    person.set_privacy(True)
    db.commit_person(person, trans)

The transaction message is user-visible in the Undo history; translate it.

Declaring dependencies

Addons may need Python packages or system tools that aren't part of Gramps' core dependencies. Declare these in the registration so the plugin manager can surface a clear "missing X" message instead of a generic import failure.

`requires_mod` — Python modules

requires_mod = ["PIL", "lxml"]

Uses the importable module name (what you import), not the PyPI distribution name. PIL not Pillow, lxml fine either way (matches), yaml not PyYAML. Verify before you push:

from importlib.util import find_spec
assert find_spec("PIL") is not None

A mismatch shows up the first time the addon's tests run against a clean install — the import fails. Always verify the name with find_spec before publishing.

`requires_gi` — GObject Introspection bindings

requires_gi = [("GExiv2", "0.10")]

A list of (namespace, version) tuples. The user has to install these through their OS package manager; Gramps cannot install GI bindings. The version pin must match what your code actually imports — and on gramps61 the version handling for GExiv2 was rewritten (addons-source PR 829), so a requires_gi pinned for one branch isn't guaranteed correct on the other. Verify against the target branch's related code before assuming a cherry-pick is correct.

`requires_exe` — Executables on PATH

requires_exe = ["graphviz", "dot"]

External binaries the user must have installed. Gramps checks PATH for them and surfaces a missing-dependency message.

`depends_on` — Other addons

depends_on = ["libwebconnect"]

Other addons that must load first. The plugin manager resolves these automatically when the user installs your addon. Circular dependencies break the load and disable the addon — the loader chooses safety over guessing.

Configuration and persistent settings

For settings that should survive between sessions, Gramps' configuration manager handles the file I/O and migration; you only declare the keys.

from gramps.gen.config import config as configman

config = configman.register_manager("my_addon")
config.register("section.key1", default_value)
config.register("section.key2", another_default)
config.load()       # read existing settings file, if any
config.save()       # write defaults out if the file didn't exist

config.get("section.key1") and config.set("section.key1", value) read and write at runtime. Gramplets persist via the lifecycle hook:

def on_save(self):
    config.save()

The settings file lives in the addon's plugin folder by default. For a system-wide config (rare):

config = configman.register_manager("my_addon", use_config_path=True)
