Overview

Gramps doesn't have one "addon" shape — it has 14 of them, each registered with a different register(KIND, …) constant and each plugged in at a different extension point. This page is the index over all of them, with the registration constant, the UI location, the base class to subclass, and a pointer onward. Use it to answer the first question every prospective addon author asks: which kind of thing am I writing?

Source of truth for the constants: gramps/gen/plug/_pluginreg.py.

Kinds at a glance

Constant	Where it shows up	Typical use
GRAMPLET	Dashboard, sidebar, bottombar	Lightweight widget over the current selection
VIEW	Main view area	A full alternative way to browse the tree
REPORT	Reports menu	Text / graphical output (PDF, HTML, ODF, …) using the docgen interface
TOOL	Tools menu	Operates on the database, optionally writing inside a transaction
IMPORT	File → Import	Reads an external format into the tree
EXPORT	File → Export	Writes the tree to an external format
DOCGEN	Report output backends	Adds a new output format / paper backend used by reports
QUICKVIEW	Right-click context menus	Single-call short report on a selected object (formerly QUICKREPORT)
SIDEBAR	Sidebar navigator	Adds a new sidebar category
MAPSERVICE	Geography view	Adds a new map tile provider
RELCALC	Relationships view	Per-locale relationship calculator
RULE	Filter editor	Adds a new filter rule for an object type
DATABASE	New tree backend selection	Adds support for another database backend
THUMBNAILER	Media handling	Adds a thumbnail generator for an additional media format
CITE	Source citations	Adds a citation formatter style
GENERAL	(varies)	Catch-all for libraries / pluggable categories (WEBSTUFF, Filters, …)

QUICKREPORT is the legacy name for QUICKVIEW; the integer constant is identical (gramps/gen/plug/_pluginreg.py line 83). New addons use QUICKVIEW; existing ones continue to work.

Per-kind notes

The notes below cover the kinds an addon author is likely to write. Kinds with deeper conventions get their own section; the rest are summarised in one paragraph each. For full attribute lists per kind, the authoritative reference is the expand_* functions in _pluginreg.py.

GRAMPLET

Where it shows up: docked in the Dashboard, sidebar, or bottombar of any view; can be detached into a floating window.

Base class: subclass gramps.gen.plug.Gramplet. Override init() (constructor hook, runs once), main() (re-run on update), db_changed() (called when the active database changes), and active_changed() (called when the active person / family / etc. changes).

Minimum-viable shape:

<syntaxhighlight lang="python">from gramps.gen.plug import Gramplet

class MyGramplet(Gramplet):

   def init(self):
       self.set_text(_("Hello"))</syntaxhighlight>

Registration: see 02-get-started for the full call. Required Gramplet-specific fields are gramplet (the class name) and gramplet_title (the user-visible tab title).

Tutorial: 03-tutorials → A live Gramplet.

REPORT

Where it shows up: Reports menu, organised by category.

Base class: subclass gramps.gen.plug.report.Report. Override write_report() to emit content. Pair with an options class that subclasses gramps.gen.plug.report.MenuReportOptions and overrides add_menu_options() (to define user-adjustable options) and make_default_style() (to define paragraph and font styles).

Categories (_pluginreg.py L141–L149): CATEGORY_TEXT, CATEGORY_DRAW, CATEGORY_CODE, CATEGORY_WEB, CATEGORY_BOOK, CATEGORY_GRAPHVIZ, CATEGORY_TREE. Text and Draw reports go through the docgen abstraction, so the same report can emit PDF / HTML / ODF without per-format code.

Report modes (report_modes field): REPORT_MODE_GUI (dialog-driven), REPORT_MODE_BKI (book item), REPORT_MODE_CLI (command line). Most addons combine GUI + CLI.

Tutorial: 03-tutorials → A text Report.

TOOL

Where it shows up: Tools menu, optionally categorised.

Base class: subclass a class from gramps.gui.plug.tool (typically Tool or BatchTool). Override the constructor — Gramps passes (dbstate, user, options_class, name, callback=None). Tools that mutate the database must do so inside a DbTxn.

Categories (_pluginreg.py L154–L159): TOOL_DEBUG, TOOL_ANAL, TOOL_DBPROC, TOOL_DBFIX, TOOL_REVCTL, TOOL_UTILS. Choose the one that matches what the tool actually does — TOOL_DBFIX for repairs, TOOL_ANAL for read-only analysis, TOOL_UTILS for generic utilities.

Tool modes (tool_modes field, _pluginreg.py L183–L184): TOOL_MODE_GUI and TOOL_MODE_CLI. A pure-data tool should support both so a power user can scriptit.

Tutorial: 03-tutorials → A simple Tool.

QUICKVIEW

Where it shows up: right-click context menus on the selected object in views and editors.

Entry point: a run(database, document, person_or_family_or_…) function declared in the implementation module and pointed to by the runfunc field. No class subclassing required.

Categories (_pluginreg.py L163–L174): CATEGORY_QR_PERSON, CATEGORY_QR_FAMILY, CATEGORY_QR_EVENT, CATEGORY_QR_SOURCE, CATEGORY_QR_PLACE, CATEGORY_QR_REPOSITORY, CATEGORY_QR_NOTE, CATEGORY_QR_DATE, CATEGORY_QR_MEDIA, CATEGORY_QR_CITATION, CATEGORY_QR_SOURCE_OR_CITATION, CATEGORY_QR_MISC. The category determines which context menu the entry appears in.

Quick Views are deliberately the shortest path to a usable report — written against the gramps.gen.simple API (SimpleAccess, SimpleDoc), they hide most of the docgen complexity. Reach for a full REPORT only when you need styles, paragraph layout, or multiple output formats.

Tutorial: 03-tutorials → A Quick View.

RULE

Where it shows up: the Add Rule dialog when the user composes a custom filter from the Filter Editor; available wherever filters are.

Base class: subclass the right rule base from gramps.gen.filters.rules — pick the namespace-specific base (gramps.gen.filters.rules.person.Rule, …family.Rule, etc.) that matches the object type your rule applies to. Set the class attributes name, description, category, and labels (the user-prompted arguments); implement apply(db, obj) to return True / False.

Tutorial: 03-tutorials → A custom filter Rule.

VIEW

Where it shows up: the main view area; available from the navigator once registered.

Base class: subclass an appropriate view from gramps.gui.views (NavigationView, ListView, PageView). Views are the heaviest addon kind — they own the entire display surface and the keyboard / mouse interaction. Most addons should reach for GRAMPLET instead and only graduate to VIEW when the gramplet outgrows its container.

Live examples: CombinedView, LifeLineChartView, QuiltView — read one before writing your own.

IMPORT / EXPORT

Where they show up: File → Import / Export, with the new format appearing in the format dropdown.

Entry point: a module-level function. Importers receive (database, filename, user); exporters receive (database, filename, error_dialog, option_box, callback) (signatures vary slightly by Gramps minor; the safest move is to read a live importer/exporter and copy the shape).

Live examples: the GEDCOM (gramps/plugins/importer/importgedcom.py, …/exporter/exportgedcom.py) and JSON importers/exporters in core are the canonical references.

DOCGEN

Where it shows up: as a new output format in any Report's options dialog; not user-launched on its own.

Base class: subclass gramps.gen.plug.docgen.BaseDoc (or the text/draw subclasses depending on what kind of output you generate). A DocGen implements the primitives — paragraphs, tables, drawing commands — that the abstract Report classes call into. Authors usually only write a new DocGen to add a new output format (e.g. a new word-processor file type); it's a relatively rare addon kind.

SIDEBAR

Where it shows up: the navigator on the left of the main window; each SIDEBAR plugin adds one category.

Base class: subclass gramps.gui.sidebar.Sidebar. Core categories (People, Families, Events, …) are themselves implemented this way, so the canonical examples ship in core under gramps/gui/sidebar/.

MAPSERVICE

Where it shows up: the Geography views' map-source dropdown.

Base class: subclass gramps.plugins.lib.maps.osmgps.MapService and implement the URL / tile-fetch protocol for your provider. Pure tile adapters — no UI changes — so most are very small.

RELCALC

Where it shows up: wherever Gramps computes a relationship string (Relationships view, person editor, reports). One RELCALC plugin per locale.

Base class: subclass gramps.gen.relationship.RelationshipCalculator. The base class supplies all the English-language logic; subclasses override the localised strings and any kinship rules specific to the culture being modelled.

DATABASE

Where it shows up: the database-backend dropdown in tree creation.

Adds a fully alternative storage backend implementing the DbReadBase / DbWriteBase interfaces. By far the heaviest kind — the only current in-tree examples are the BSDDB and SQLite backends themselves. Treat the existence of this kind as "yes, it is possible," not "you should consider writing one."

THUMBNAILER

Where it shows up: wherever Gramps generates a media thumbnail.

Adds a generator for one additional media format. Pure-function shape: input file → thumbnail image. Use this when a media type Gramps recognises doesn't have a working thumbnailer in your environment.

CITE

Where it shows up: the citation style chooser in source / citation editors and reports.

Adds an alternative citation formatter (Chicago, MLA, Evidence Explained, …). Implements the formatting protocol expected by the source / citation code; cite an existing core formatter (gramps/plugins/cite/) for the exact shape on the branch you're targeting.

GENERAL

Where it shows up: nowhere directly — GENERAL is the escape hatch for plugin code that doesn't fit any other kind. Two main uses:

• Shared libraries — code reused across multiple addons. Set load_on_reg=True and the file gets imported at startup; everything in it becomes importable to other plugins as import <addon-id>. The libwebconnect addon, depended on by every Web Connect Pack, is the archetype.
• Pluggable categories — GENERAL plugins can declare a category string; other code can then ask the plugin manager for all GENERAL plugins of category WEBSTUFF (CSS stylesheets for the narrative website report) or Filters (filter-rule providers). New categories are rare; the published ones are documented in addons-development.

The category WEBSTUFF is the one most addon authors meet: addons that ship a stylesheet for the narrative website register as GENERAL, category="WEBSTUFF" and the website report picks them up automatically.

Multiple kinds in one addon

A single .gpr.py can call register(...) more than once. The classic case is a report that also registers a Quick View entry for the same underlying logic (gramps/plugins/quickview/all_events.py does this for events). Each register() call is independent; only the addon folder / id and the implementation file(s) are shared.

See also

• 01-overview — what an addon is, file roles.
• 02-get-started — first Gramplet end-to-end.
• 03-tutorials — per-kind walkthroughs.
• 05-fundamentals — the cross-cutting concepts every kind relies on.
• gramps/gen/plug/_pluginreg.py — the authoritative definition of all the constants and expand_* attribute lists per kind.
• 6.0 Addons — the canonical catalogue of what already exists per kind; reading a similar addon's source is your fastest second tutorial.
